Short Description:
Advantages of aluminum alloy bracket
1. ** Material characteristics ** : Aluminum alloy has the characteristics of light weight and high strength. Compared with traditional steel, the weight is greatly reduced, which is very beneficial for reducing the overall load of the building, while meeting the strength requirements of the supporting stone.
2. ** Corrosion resistance ** : Aluminum alloy surface will form a layer of dense oxide film, so that it has good corrosion resistance, in different environmental conditions, can maintain long-term performance stability, extend the service life of the support system, reduce maintenance costs.
### Supporting system composition
1. ** Main keel ** : Usually a larger aluminum alloy profile, as the main force structure of the entire support system, vertically or horizontally installed on the wall, providing the main support for the stone.
2. ** Secondary keel ** : connected with the main keel to further subdivide the support area, provide more uniform support for the stone, and rationally arrange according to the size and weight distribution of the stone.
3. ** Connector ** : used to connect the main keel with the wall, the main keel with the secondary keel and the keel with the stone and other components to ensure the stable connection of the entire system. These connectors are diverse in design, and some are adjustable to facilitate fine-tuning during installation to ensure the flatness and verticality of the stone wall.
4. ** pendant ** : directly connected with the stone, the stone is fixed on the support system. The design of the pendant should not only ensure a strong connection, but also take into account the convenience of stone installation and disassembly, and some pendants also have certain seismic and buffer functions.
### Application scenario
Widely used in all kinds of building exterior wall decoration, indoor lobby, exhibition hall and other places with high requirements for decorative effect and safety, can perfectly show the texture and beauty of stone, while ensuring the safety and reliability of wall structure.
Are you working on a project, or would you like to learn more about the system’s technical specifications, installation points, and so on?
–
陶转The aluminum alloy support system is a kind of building structure system used to support and fix the ceramic tile wall surface.
### Characteristics of aluminum alloy bracket
1. ** Material advantage **
Aluminum alloy has low density and light weight. Compared with traditional support materials such as steel, it can effectively reduce the overall weight of the building and reduce the bearing pressure of the building foundation. At the same time, it has good strength and rigidity, enough to support the weight of the ceramic tile plate, to ensure the stability of the wall structure.
- Aluminum alloys have excellent corrosion resistance. The naturally formed oxide film on its surface can resist the erosion of a variety of chemical substances, and can maintain long-term stable performance under different climatic and environmental conditions, reducing structural damage and maintenance costs caused by corrosion.
2. ** Processing performance ** : Aluminum alloy is easy to process and form, and can be made into various shapes and specifications of bracket parts according to different design needs to meet diverse architectural design and construction requirements.
### System composition
1. ** Main keel ** : As the main load-bearing component of the entire support system, the main keel is usually installed horizontally or vertically on the wall structure. It carries most of the weight from the ceramic tiles and transfers it to the main structure of the building. The main keel is generally made of aluminum alloy profiles of larger specifications to ensure sufficient strength and stability.
2. ** Secondary keel ** : connected with the main keel to further refine the support structure and provide more uniform support for the ceramic tile plate. The spacing of the secondary keel is rationally arranged according to the size, weight and design requirements of the ceramic tile plate to ensure that each ceramic tile plate can be reliably supported.
3. ** Connector ** : used to connect the main keel and the wall, the main keel and the secondary keel, as well as the support and ceramic tile plate and other components. These connectors have a variety of forms, such as bolted connectors, welded connectors, etc. Some connectors also have adjustable functions, which can fine-tune the position and Angle of the support during installation to ensure the flatness and verticality of the ceramic tile wall.
4. ** Pendant ** : directly connected with the ceramic tile plate, the ceramic tile plate is fixed on the support system. The design of the pendant should not only ensure a strong connection with the ceramic tile plate, prevent the ceramic tile plate from falling off, but also take into account the convenience of installation and disassembly, so as to adjust and maintain during the construction process.
### Application scenario
The system is suitable for the interior and exterior decoration of all kinds of buildings, especially the projects that have high requirements for the texture and durability of the building appearance. Such as commercial buildings, cultural venues, high-end residential. It can fully show the unique color, texture and texture of the ceramic tile, while using the advantages of the aluminum alloy bracket system to ensure the safety and stability of the wall.
Are you studying the application of such systems, or are you interested in specific aspects such as installation process, cost, etc.?
